2003-2024 TOYOTA 4RUNNER | 2.5 FACTORY RACE SERIES - Rear Shocks

FOX 2.5 Factory Race Series Internal Bypass Shocks

2003-2024 Toyota 4Runner (Rear)
SKU: 883-26-145

Pairs great with these front coilovers: 883-06-227

The same race-proven internal bypass technology from the fronts, now engineered specifically for the rear of your 4Runner. Bolt-on fitment with vehicle-specific tuning means you're not buying a generic shock and hoping for the best — these are built for your truck.

Patented Internal Bypass Technology
Ride zone bleed holes let fluid pass freely for a compliant, controlled feel on everyday terrain. Push the shock past the ride zone and those ports close, routing fluid through the main piston for progressive, increasing resistance — preventing hard bottoms, harsh top-outs, and absorbing landing impact.

Dual Speed Compression (DSC) Adjuster
Fine-tune compression damping from the external reservoir to dial in the rear for load, terrain, and driving style — whether you're loaded up for a trail run or running light.

Built to Last

• 2.5" impact-extruded, CNC-machined 6061-T6 aluminum body with Type III hard anodizing
• 7/8" hard chromed steel shafts
• Redundant sealing system: main seal + wiper seal + scraper seal
• External reservoir with internal floating piston (IFP) separates oil and nitrogen charge for consistent damping and cooler temps

Specs

• Travel: 9.29"
• Extended Length: 24.8"
• Compressed Length: 15.51"
• Top Mount: Stem Top
• Bottom Mount: Eyelet
• Note: Requires Extended Sway Bar Links - Contact us to add them to your order

Fits: Toyota 4Runner (confirm year fitment via FOX shock finder or contact us)
